17 Function library
17.1 Function blocks
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
17 Function library
17.1 Function blocks
This chapter describes the function blocks which are available for the inverter in the FB Editor.
Overview of function blocks available
 The system blocks are described in the chapter "System blocks". ( 1529)
 Note!
From version 06.00.00, a maximum of 65 function blocks instead of 50 can be used in the
function block interconnection. The computing power remains unchanged, i.e. the max.
computing time is approx. 300 μs.
Function block Runtime Function
L_Absolute_1
L_Absolute_2
2 μs ... converts a bipolar input signal into a unipolar output signal.
L_AddSub_1
3 μs ... adds / subtracts analog input signals.
L_AnalogSwitch_1
L_AnalogSwitch_2
L_AnalogSwitch_3
L_AnalogSwitch_4
L_AnalogSwitch_5
2 μs ... switches between two analog input signals.
L_And_1
L_And_2
L_And_3
2 μs ... ANDs three binary signals.
L_And5_1
L_And5_2
2 μs ... ANDs five binary signals.
L_Arithmetik_1
L_Arithmetik_2
L_Arithmetik_3
L_Arithmetik_4
L_Arithmetik_5
7 μs ... combines two analog signals arithmetically.
L_ArithmetikPhi_1
L_ArithmetikPhi_2
L_ArithmetikPhi_3
7 μs ... combines two angle signals arithmetically.
L_CalcDiameter_1
2 μs ... can calculate the reel diameter from line speed and winding speed.
• This FB is available from version 11.00.00.
L_Compare_1
L_Compare_2
L_Compare_3
L_Compare_4
L_Compare_5
5 μs ... compares two analog signals and can be used e.g. to implement a
trigger.
L_ComparePhi_1
L_ComparePhi_2
L_ComparePhi_3
L_ComparePhi_4
L_ComparePhi_5
5 μs... compares two angle signals.
