Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23 695
10 Oscilloscope function
10.3 Managing oscillograms
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
10.3 Managing oscillograms
If several oscillograms are loaded in the oscilloscope at the same time, the oscillogram to be
displayed is selected via the corresponding tab below the toolbar. In general, the following
oscillograms are to be distinguished:
Device oscillogram
The device oscillogram is the only oscillogram which can be used to establish a connection to the
target system to carry out an oscilloscope measurement.
MERGE oscillogram
If two or more oscillograms are loaded in the oscilloscope, a "MERGE" tab is available.
In the merge tab, several characteristics from the currently loaded data records can be overlaid,
e.g. to compare signal characteristics from different recordings. Overlay function
( 698)
Loaded oscillogram
An oscillogram loaded from a file.
10.3.1 Commenting the oscillogram
The Comment text field serves to enter a comment on the selected oscillogram.
If you execute the Saving the oscillogram in a file
command, the comment is saved together
with the oscillogram in the file.
