11.8.1 Available process data objects
The number of available process data objects for inverters of the 8400 series depends on the device
version:
Receive PDOs (RPDOs)
The process data objects transmitted from the system bus to
the drive are processed via the
LP_CanIn1
... LP_CanIn4 port blocks.
• Every port block provides 4 words (2 bytes/word). The data of every first word are provided in a
bit decoded manner (bit 0 ... 15).
• The first word of the LP_CanIn1
port block is defined as control word wCtrl. The wCtrl control
word does not
have a permanent connection to the device control and can be used as required.
The predefined assignment of the wCtrl control word in the C00007
= "30: CAN" control mode
depends on the technology application selected in C00005
:
• TA "Actuating drive speed":
Process data assignment for fieldbus communication
( 394)
• TA "Abschaltpositionierung":
Process data assignment for fieldbus communication
( 484)
Transmit PDOs (TPDOs)
The process data transmitted from the drive to
the system bus are processed via the
LP_CanOut1
... LP_CanOut4 port blocks.
• Every port block receives 4 words (2 bytes/word). The data of every first word are transmitted
bit by bit (bit 0 ... 15).
• The first word of the LP_CanOut1
port block is defined as the wState status word. The wState
status word does not
have a permanent connection to the device control and can be used as
required.
• For a predefined assignment, see the wDeviceStatusWord status word
of the drive interface.
Process data object Version
BaseLine C StateLine C
HighLine C
TopLine C
RPDO1 | Port block "LP_CanIn1"
 
RPDO2 | "LP_CanIn2" port block
 
RPDO3 | "LP_CanIn3" port block

RPDO4 | "LP_CanIn4" port block

(from version 15.00.00)
TPDO1 | "LP_CanOut1" port block  
TPDO2 | "LP_CanOut2" port block
 
TPDO3 | "LP_CanOut3" port block 
TPDO4 | "LP_CanOut4" port block

(from version 15.00.00)
