17 Function library
17.1 Function blocks | L_Interpolator_1
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
17.1.95.2 Signal monitoring
If signal monitoring is active (C00950/2 = 1), the signal characteristic of the dnPhIn_p input signal
is continued even if the data telegram is missing (setpoint selection via CAN).
Monitoring is performed on the basis of the dnPhIn_p position setpoint and the bSpeedAct0 status
signal:
•If the dnPhIn_p position setpoint remains the same in the next device cycle, it is either because
the speed is zero or because no data telegram has been received.
• The evaluation of the bSpeedAct0 status signal gives information about which reason applies.
This status signal needs to be transmitted by the setpoint source to ensure trouble-free
operation:
• bSpeedAct0 = FALSE means that the speed is not
zero, so an error is assumed: The signal
characteristic of the dnPhIn_p input signal is completed (the current slope is retained).
• bSpeedAct0 = TRUE means that the speed is
zero, so the unchanged position setpoint is not
treated as an error.
• If the number of missing data telegrams exceeds the limit value parameterised in C00952
, the
bSignalError output is set to TRUE.
•The bSignalError output is automatically reset to FALSE if correct signals are detected at
dnPhIn_p and bSpeedAct0 again.
 Note!
Do not change the number of interpolation steps during operation. Otherwise the
interpolation becomes inaccurate.
 Note!
The nNIn_a analog value is not monitored!
