17.2.1 LS_AnalogInput
Interface to the analog input terminals.
17.2.2 LS_AnalogOutput
Interface to the analog output terminals.
17.2.3 LS_CANManagement
Control of internal functions of the CAN driver and display of the "Operational" status as well as the
node address.
17.2.4 LS_DataAccess
Only for Lenze-internal use.
17.2.5 LS_DeviceMonitor
Motor control status signals.
17.2.6 LS_DigitalInput
Interface to the digital input terminals.
17.2.7 LS_DigitalOutput
Interface to the digital output terminals.
 For a detailed description see the main chapter "I/O terminals":
Internal interfaces | System block "LS_AnalogInput"
( 355)
 For a detailed description see the main chapter "I/O terminals":
Internal interfaces | System block "LS_AnalogInput"
( 355)
 For a detailed description see the main chapter "System bus CAN on board":
Internal interfaces | System block "LS_CANManagement"
( 779)
 For a detailed description see the main chapter "Motor control (MCTRL)":
Internal status signals | System block "LS_DeviceMonitor"
( 319)
 For a detailed description see the main chapter "I/O terminals":
Internal interfaces | System block "LS_DigitalInput"
( 336)
