5 Motor control (MCTRL)
5.9 Servo control (SC)
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
5.9.3.1 Parameterising the encoder/feedback system
Required settings:
1. Parameterise the function of the digital inputs 1 and 2 as the encoder input in C00115
.
2. Set the encoder increments in C00420/1
.
3. Select the speed sensor in C00495
.
4. Adapt the filter time of the actual speed filter in C00497
.
5. In the case of encoders with a very low resolution (number of increments < 120 increments):
Change the encoder evaluation procedure in C00496
if necessary.
