Lenze 8400 - Page 912

15 Parameter reference
15.2 Parameter list
912
Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00496
C00497
C00505
Parameter | Name:
C00496 | Encoder evaluation method DigIn12
Data type: UNSIGNED_8
Index: 24079
d
= 5E0F
h
Encoder/feedback system
Selection list (Lenze setting printed in bold) Info
0 High-resolution encoders High-precision procedure for high-resolution encoders
(>=512 increments)
1 Low-resolution encoder (StateLine) High-precision procedure for low-resolution encoders
(<=128 increments)
2 Comb. encoder procedure Combination of the first two procedures as a function of
the speed (recommended procedure)
3 Edge-counting procedure Simple edge counting procedure with adjustable
scanning time (C00425
)
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00497 | Filter time constant
Data type: UNSIGNED_16
Index: 24078
d
= 5E0E
h
From version 03.00.00
Encoder/feedback system
Setting range (min. value | unit | max. value)
0.0 ms 500.0
Subcodes Lenze setting Info
C00497/1 1.0 ms FreqIn12: Encoder filter time
C00497/2 1.0 ms FreqIn67: Encoder filter time
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 10
Parameter | Name:
C00505 | Password data
Data type: VISIBLE_STRING
Index: 24070
d
= 5E06
h
From version 06.00.00
Device access protection
Subcodes Lenze setting Info
C00505/1 MasterPin
C00505/2 Binding ID
C00505/3 Password
 Read access  Write access  CINH  PLC-STOP  No transfer  COM  MOT Character length: 16
