8 Basic drive functions (MCK)
8.12 Holding brake control
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
8.12.2.2 Functional settings
The following bit coded functional settings for the holding brake control can be made in C02582:
Bit Option Info
Bit 0 bMBrakeReleaseOut invert. Activation of inverted control
•"1" ≡ Inverted logic of the trigger signal for the holding brake
control switching element
Bit 1 Horizontal brake protection Brake response in case of pulse inhibit
•"1" ≡ In the case of a pulse inhibit, the actual speed value is
monitored which must reach the "Close" threshold value to cause
the holding brake to be applied.
Note:
• This function is only active if bit 3 (horizontal/winding
technology) is set as well. The function is used in order that, when
the controller is inhibited, the holding brake of a drive with
horizontal traverse path does not wear out during rotation.
• With vertical motion (bit 3 = 0), this function is not active.
Especially with hoists and activated pulse inhibit of the inverter,
an immediate application of the brake is essential for safety-
related reasons!
Bit 2 with hoist inv. feedfwd. control Direction of feedforward control with vertical/hoist technology:
•"0" ≡ Positive direction
•"1" ≡ Negative direction
Note:
Reversal (Ccw) is then considered.
Bit 3 Horizontal application Direction of movement of the axis
•"0" ≡ The axis performs vertical movements. Gravitational
acceleration causes movements.
•"1" ≡ The direction of the axis is horizontal or rotary. The
gravitational acceleration does not cause any movement.
Bit 4 Feedforward control C2581
(from version 06.00.00)
Selection of the feedforward control value
•"0" ≡ Automatic selection.
• The torque saved at the last stop is used.
•"1" ≡ Manual selection.
• bMBrakeStartValue2 = FALSE: The feedforward control value 1
set in C02581/4
is used.
• bMBrakeStartValue2 = TRUE: The feedforward control value set
in C02581/5
is used.
Bit 5 Feedback monitoring
(from version 06.00.00)
Activation of status monitoring
•"1" ≡ The bMBrakeApplied input for status detection of the brake
(via a switching contact at the brake) is monitored after the
waiting time set in C02589/3
has expired.
Bit 6 Sync ramp L_NSet_1
(from version 11.00.00)
Selection of the ramp time for the synchronisation process to
setpoint speed after the brake opening time has elapsed
Revised behaviour from version 11.00.00:
•"1" ≡ The ramp time of the effective acceleration of the ramp
function generator (L_NSet_1
) is used (Lenze setting).
•"0" ≡ As before, the ramp time set in C02610/1
is used.
Note:
The changeover can be dynamically both via the ramp parameter
and via bit 6.
Bit 7 Reserved
