Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23 1544
17 Function library
17.2 System blocks | LS_ParFree_b
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
17.2.21 LS_ParFree_b
This system block outputs 32 parameterisable digital signals.
Outputs
Parameters
Designator
Data type
Value/meaning
bPar1 ... bPar32
BOOL
From version 11.00.00 onwards:
bC470_1 ... bC470_32
Output of the signal levels (FALSE/TRUE) parameterised in C00470/1...32
Note: From version 11.00.00 the outputs are named according to the respective
setting parameter for an easier allocation.
Parameters Possible settings Info
C00470/1...32
Selection of signal levels to be output
• Bit 0 ... 31 = bPar1 ... bPar32
0 "FALSE" signal is output
1"TRUE" signal is output
E3DU
E3DU
E3DU
E3DU
E3DU
&
&
&
&
&
/6B3DU)UHHBE
