15 Parameter reference
15.2 Parameter list
904
Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00469
C00470
C00471
Parameter | Name:
C00469 | Keypad: Fct. STOP key
Data type: INTEGER_32
Index: 24106
d
= 5E2A
h
Selection of the function for the STOP key on the keypad
Selection list (Lenze setting printed in bold) Info
0 No function STOP key does not have any function
1 Inhibit inverter STOP key sets controller inhibit in the drive
2 Activate quick stop STOP key sets quick stop in the drive
4 Inhibit inverter and reset error From version 14.00.00
STOP key sets controller inhibit in the drive. An error
reset is carried out at the same time.
5 Activate quick stop and reset error From version 14.00.00
STOP key sets quick stop in the drive. An error reset is
carried out at the same time.
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00470 | LS_ParFree_b
Data type: UNSIGNED_8
Index: 24105
d
= 5E29
h
The LS_ParFree_b SB: Setting of the signal level to be output
Selection list
0False
1True
Subcodes Lenze setting Info
C00470/1 0: FALSE Signal level for output bPar1 ... bPar32
C00470/...
C00470/32
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00471 | LS_ParFree
Data type: UNSIGNED_16
Index: 24104
d
= 5E28
h
The LS_ParFree SB: Setting of the words to be output
Setting range (min. hex value | max. hex value)
0x0000 0xFFFF
Value is bit-coded:
Bit 0 Bit0
... ...
Bit 15 Bit15
Subcodes Lenze setting Info
C00471/1 0x0000 Value for output wPar1 ... wPar32
C00471/...
C00471/32
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT
