Lenze 8400 - Page 905

Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23 905
15 Parameter reference
15.2 Parameter list
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00472
C00473
C00474
Parameter | Name:
C00472 | LS_ParFree_a
Data type: INTEGER_16
Index: 24103
d
= 5E27
h
The LS_ParFree_a SB: Setting of the analog signals to be output
Setting range (min. value | unit | max. value)
-199.99 % 199.99
Subcodes Lenze setting Info
C00472/1 0.00 % Value for output nPar1_a
C00472/2 0.00 % Value for output nPar2_a
C00472/3 100.00 % Value for output nPar3_a
C00472/4 100.00 % Value for output nPar4_a
C00472/5 0.00 % Value for output nPar5_a
C00472/6 0.00 % Value for output nPar6_a
C00472/7 0.00 % Value for output nPar7_a
C00472/8 0.00 % Value for output nPar8_a
C00472/9 0.00 % Value for output nPar9_a
C00472/10 0.00 % Value for output nPar10_a
C00472/11 0.00 % Value for output nPar11_a
C00472/12 0.00 % Value for output nPar12_a
C00472/13 0.00 % Value for output nPar13_a
C00472/14 0.00 % Value for output nPar14_a
C00472/15 0.00 % Value for output nPar15_a
C00472/16 0.00 % Value for output nPar16_a
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
Parameter | Name:
C00473 | LS_ParFree_v
Data type: INTEGER_16
Index: 24102
d
= 5E26
h
The LS_ParFree_v SB: Setting of the speed signals to be output
Setting range (min. value | unit | max. value)
-32767 Incr./ms 32767
Subcodes Lenze setting Info
C00473/1 0 incr./ms Values for output nPar1_v ... nPar8_v
C00473/...
C00473/8
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00474 | LS_ParFree_p
Data type: INTEGER_32
Index: 24101
d
= 5E25
h
SB LS_ParFree_p: Setting of the position signals to be output
Setting range (min. value | unit | max. value)
-2147483647 Incr. 2147483647
