Lenze 8400 - Page 906

15 Parameter reference
15.2 Parameter list
906
Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00475
C00476
Subcodes Lenze setting Info
C00474/1 0 incr. Values for output dnPar1_p ... dnPar8_p
C00474/...
C00474/8
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00474 | LS_ParFree_p
Data type: INTEGER_32
Index: 24101
d
= 5E25
h
Parameter | Name:
C00475 | LS_ParFreeUnit_1_2
Data type: INTEGER_32
Index: 24100
d
= 5E24
h
From version 11.00.00
SB LS_ParFreeUnit
/ LS_ParFreeUnit_2: Setting of the position signals to be output
Setting range (min. value | unit | max. value)
-214748.3647 units 214748.3647
Subcodes Lenze setting Info
C00475/1 0.0000 units Values for output dnC475_1 ... dnC475_32
C00475/...
C00475/32
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 10000
Parameter | Name:
C00476 | LS_ParFree_a_2
Data type: INTEGER_16
Index: 24099
d
= 5E23
h
From version 11.00.00
SB LS_ParFree_a_2
: Setting of the analog signals to be output
Setting range (min. value | unit | max. value)
-199.99 % 199.99
Subcodes Lenze setting Info
C00476/1 0.00 % Value for output nC476_1_a
C00476/2 0.00 % Value for output nC476_2_a
C00476/3 0.00 % Value for output nC476_3_a
C00476/4 0.00 % Value for output nC476_4_a
C00476/5 0.00 % Value for output nC476_5_a
C00476/6 0.00 % Value for output nC476_6_a
C00476/7 0.00 % Value for output nC476_7_a
C00476/8 0.00 % Value for output nC476_8_a
C00476/9 0.00 % Value for output nC476_9_a
C00476/10 0.00 % Value for output nC476_10_a
C00476/11 0.00 % Value for output nC476_11_a
C00476/12 0.00 % Value for output nC476_12_a
C00476/13 0.00 % Value for output nC476_13_a
C00476/14 0.00 % Value for output nC476_14_a
C00476/15 0.00 % Value for output nC476_15_a
C00476/16 0.00 % Value for output nC476_16_a
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
