5 Motor control (MCTRL)
5.13 Braking operation/brake energy management
286
Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
5.13 Braking operation/brake energy management
When braking electrical motors, the kinetic energy of the drive train is fed back regeneratively to the
DC bus. This energy results in a boost of the DC-bus voltage.
• Several different strategies can serve to avoid DC-bus overvoltages:
• Use of a brake resistor
• Stopping of the ramp function generator if brake chopper threshold exceeded (RFG_Stop)
• Use of the "inverter motor brake" function (from version 04.00.00)
• Combination of the above named options
• In the case of inverters with a 3-phase supply, the following is also possible:
• Coupling of the inverters in a DC-bus connection
• Recovery of regenerative energy with a regenerative module
Stop!
If the connected brake resistor is smaller than required, the brake chopper can be
destroyed!
• Appropriate protective measures are described in subchapter "Avoiding thermal
overload of the brake resistor". ( 294)
If no brake resistor or regenerative module is used, the overvoltage switch-off ("oU
") may
respond, e.g. in case of short deceleration times during feedback operation. Error
messages of the operating system ( 647)
