5 Motor control (MCTRL)
This chapter provides information on the parameter setting of the inverter's internal motor control.
Topics:
Basic settings:
Motor selection/Motor data
Selecting the control mode
Defining current and speed limits
Description of the motor control types:
V/f characteristic control (VFCplus)
V/f characteristic control - energy-saving (VFCplusEco)
V/f control (VFCplus + encoder)
Sensorless vector control (SLVC)
Sensorless control for synchronous motors (SLPSM)
Servo control (SC)
Parameterisable additional functions:
Selection of switching frequency
Operation with increased rated power
Flying restart function
DC-injection braking
Slip compensation
Oscillation damping
Phase sequence reversal for correcting misconnected UVW motor phases
Further topics:
Encoder/feedback system
Position control/additive speed specification
Braking operation/brake energy management
Monitoring
Internal interfaces (process signals):
Internal interfaces | System block "LS_MotorInterface"
Internal status signals | System block "LS_DeviceMonitor"
