16.6 Printing the interconnection
The interconnection can be printed for documentation purposes, optionally on one page, on four
pages, or not scaled.
 Tip!
By clicking the icon in the FB Editor toolbar, you can get a print view before printing.
 How to print the interconnection:
1. In the FB Editor toolbar, click the icon.
•The Circuit print size dialog box is displayed.
2. Select the desired size and press OK.
• The standard dialog box Print appears.
3. Press OK to start the printing process.
