Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23 1165
15 Parameter reference
15.5 Selection list - digital signals
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
15.5 Selection list - digital signals
This selection list is relevant for the following
configuration parameters:
Parameters
C00411 L_SignalMonitor_b: Signal sources
C00621
System connection list: Bool
C00701
LA_NCtrl: Digital connection list
C00711
LA_TabPos: Digital connection list
C00761
LA_SwitchPos: Digital connection list
Selection list - digital signals
0 Not connected
1000 LA_NCtrl: bDriveReady
1001 LA_NCtrl: bDriveFail
1002 LA_NCtrl: bCInhActive
1003 LA_NCtrl: bQSPIsActive
1004 LA_NCtrl: bSpeedCcw
1005 LA_NCtrl: bSpeedActCompare
1008 LA_NCtrl: bGPDigitalDelayOut
1009 LA_NCtrl: bGPLogicOut
1010 LA_NCtrl: bGPSignalOut1
1011 LA_NCtrl: bGPSignalOut2
1012 LA_NCtrl: bGPSignalOut3
1013 LA_NCtrl: bGPSignalOut4
1014 LA_NCtrl: bOverLoadActive
1015 LA_NCtrl: bMBrakeReleaseOut
1016 LA_NCtrl: bMBrakeReleased
1017 LA_NCtrl: bGPCompareOut
1018 LA_NCtrl: bUnderLoadActive
1019 LA_NCtrl: bImaxActive
1020 LA_NCtrl: bSpeedSetReached
1021 LA_NCtrl: bSpeedActEqSet
1022 LA_NCtrl: bGPDFlipFlop_Out
1023 LA_NCtrl: bGPDFlipFlop_NegOut
1029 LA_NCtrl: bFreeOut1
1030 LA_NCtrl: bFreeOut2
1031 LA_NCtrl: bFreeOut3
1032 LA_NCtrl: bFreeOut4
1033 LA_NCtrl: bFreeOut5
1034 LA_NCtrl: bFreeOut6
1035 LA_NCtrl: bFreeOut7
1036 LA_NCtrl: bFreeOut8
1100 LA_TabPos: bDriveFail
1101 LA_TabPos: bDriveReady
1102 LA_TabPos: bCInhActive
1103 LA_TabPos: bQSPIsActive
1104 LA_TabPos: bSpeedCcw
1105 LA_TabPos: bSpeedActCompare
1106 LA_TabPos: bImaxActive
1107 LA_TabPos: bSpeedSetReached
1108 LA_TabPos: bMBrakeReleaseOut
1109 LA_TabPos: bMBrakeReleased
1110 LA_TabPos: bHomeDone
1111 LA_TabPos: bHomePosAvailable
1112 LA_TabPos: bProfileDone
1113 LA_TabPos: bProfileBusy
1114 LA_TabPos: bAccelerating
1115 LA_TabPos: bConstantDuty
1116 LA_TabPos: bDecelerating
1117 LA_TabPos: bDwellTime
1118 LA_TabPos: bInTarget
1119 LA_TabPos: bGPDigitalDelayOut
1120 LA_TabPos: bGPLogicOut
1121 LA_TabPos: bGPCompareOut
1122 LA_TabPos: bGPSignalOut1
1123 LA_TabPos: bGPSignalOut2
1124 LA_TabPos: bGPSignalOut3
1125 LA_TabPos: bGPSignalOut4
1126 LA_TabPos: bGPDFlipFlop_Out
1127 LA_TabPos: bGPDFlipFlop_NegOut
1128 LA_TabPos: bGPCounter1Equal
1129 LA_TabPos: bFreeOut1
1130 LA_TabPos: bFreeOut2
1131 LA_TabPos: bFreeOut3
1132 LA_TabPos: bFreeOut4
1133 LA_TabPos: bFreeOut5
1134 LA_TabPos: bFreeOut6
1135 LA_TabPos: bFreeOut7
1136 LA_TabPos: bFreeOut8
1200 LA_SwitchPos: bDriveFail
1201 LA_SwitchPos: bWarningActive
1202 LA_SwitchPos: bSafeTorqueOff
1203 LA_SwitchPos: bDriveReady
1204 LA_SwitchPos: bCInhActive
1205 LA_SwitchPos: bImpIsActive
1206 LA_SwitchPos: bQSPIsActive
1207 LA_SwitchPos: bSpeedCcw
1208 LA_SwitchPos: bSpeedActCompare
1209 LA_SwitchPos: bImaxActive
1210 LA_SwitchPos: bSpeedSetReached
1211 LA_SwitchPos: bSpeedActEqSet
1212 LA_SwitchPos: bMBrakeReleaseOut
1213 LA_SwitchPos: bMBrakeReleased
1214 LA_SwitchPos: bGPDigitalDelayOut
1215 LA_SwitchPos: bGPLogicOut
1216 LA_SwitchPos: bGPCompareOut
1217 LA_SwitchPos: bGPDFlipFlop_Out
1218 LA_SwitchPos: bGPDFlipFlop_NegOut
1219 LA_SwitchPos: bGPSignalOut1
1220 LA_SwitchPos: bGPSignalOut2
1221 LA_SwitchPos: bGPSignalOut3
Selection list - digital signals
