15 Parameter reference
15.2 Parameter list
890
Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00410
C00411
C00412
Parameter | Name:
C00410 | L_SignalMonitor_a: Signal sources
Data type: UNSIGNED_16
Index: 24165
d
= 5E65
h
The L_SignalMonitor_a FB: Selection of the signal sources
Selection list
See selection list - analog signals
Subcodes Lenze setting Info
C00410/1 0: Not connected Signal source for output nOut1_a
C00410/2 0: Not connected Signal source for output nOut2_a
C00410/3 0: Not connected Signal source for output nOut3_a
C00410/4 0: Not connected Signal source for output nOut4_a
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00411 | L_SignalMonitor_b: Signal sources
Data type: UNSIGNED_16
Index: 24164
d
= 5E64
h
The L_SignalMonitor_b FB: Selection of the signal sources
Selection list
See selection list - digital signals
Subcodes Lenze setting Info
C00411/1 0: Not connected Signal source for output bOut1
C00411/2 0: Not connected Signal source for output bOut2
C00411/3 0: Not connected Signal source for output bOut3
C00411/4 0: Not connected Signal source for output bOut4
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00412 | L_SignalMonitor_b: Inversion
Data type: UNSIGNED_8
Index: 24163
d
= 5E63
h
The L_SignalMonitor_b FB: Inversion of the binary outputs
Setting range (min. hex value | max. hex value) Lenze setting
0x00 0xFF 0x00 (decimal: 0)
Value is bit-coded: ( =bit set) Info
Bit 0  bOut1 inverted Bit set = inversion active
Bit 1  bOut2 inverted
Bit 2  bOut3 inverted
Bit 3  bOut4 inverted
Bit 4  Reserved
Bit 5  Reserved
Bit 6  Reserved
Bit 7  Reserved
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT
