15 Parameter reference
15.2 Parameter list
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00408
C00409
Parameter | Name:
C00408 | LP_CanIn mapping selection
Data type: UNSIGNED_8
Index: 24167
d
= 5E67
h
From version 02.00.00
Selection of the mapping source for port blocks LP_CanIn1...4
CAN port block
Selection list Info
0CanIn CanIn
1 Par.C409|C407 Mapping configured in C00409
Subcodes Lenze setting Info
C00408/1 0: CanIn Mapping selection LP_CanIn1
C00408/2 0: CanIn Mapping selection LP_CanIn2
C00408/3 0: CanIn Mapping selection LP_CanIn3
C00408/4 0: CanIn Mapping selection LP_CanIn4
• From version 15.00.00
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00409 | LP_CanIn Mapping
Data type: UNSIGNED_16
Index: 24166
d
= 5E66
h
From version 02.00.00
Mapping for port blocks LP_CanIn1...4
• These settings are ORed with the mapping settings for the double words in C00407/x
.
CAN port block
Setting range (min. value | unit | max. value)
0 65535
Subcodes Lenze setting Info
C00409/1 0 LP_CanIn1
:wCtrl MapVal
C00409/2 0 LP_CanIn1:wIn2 MapVal
C00409/3 0 LP_CanIn1
:wIn3 MapVal
C00409/4 0 LP_CanIn1
:wIn4 MapVal
C00409/5 0 LP_CanIn2:wIn1 MapVal
C00409/6 0 LP_CanIn2
:wIn2 MapVal
C00409/7 0 LP_CanIn2
:wIn3 MapVal
C00409/8 0 LP_CanIn2:wIn4 MapVal
C00409/9 0 LP_CanIn3
:wIn1MapVal
C00409/10 0 LP_CanIn3
:wIn2 MapVal
C00409/11 0 LP_CanIn3
:wIn3 MapVal
C00409/12 0 LP_CanIn3
:wIn4 MapVal
C00409/13 0 LP_CanIn4
:wIn1 MapVal
• From version 15.00.00
C00409/14 0 LP_CanIn4
:wIn2 MapVal
• From version 15.00.00
C00409/15 0 LP_CanIn4
:wIn3 MapVal
• From version 15.00.00
C00409/16 0 LP_CanIn4
:wIn4 MapVal
• From version 15.00.00
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
