15 Parameter reference
15.2 Parameter list
888
Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00401
C00407
Parameter | Name:
C00401 | CANxInOut: Inversion
Data type: UNSIGNED_16
Index: 24174
d
= 5E6E
h
From version 02.00.00
This parameter serves to invert the control/status bits of the CAN port blocks.
CAN port block
Setting range (min. hex value | max. hex value)
0x0000 0xFFFF
Value is bit-coded: Info
Bit 0 Active Bit set = bit is inverted
... ...
Bit 15 Active
Subcodes Lenze setting Info
C00401/1 0x0000 Inversion of LP_CanIn1.bCtrl1_B0...15
C00401/2 0x0000 Inversion of LP_CanOut1.bState1_B0...15
C00401/3 0x0000 Inversion of LP_CanIn2.bIn1_B0...15
C00401/4 0x0000 Inversion of LP_CanOut2.bOut1_B0...15
C00401/5 0x0000 Inversion of LP_CanIn3.bIn1_B0...15
C00401/6 0x0000 Inversion of LP_CanOut3.bOut1_B0...15
C00401/7 0x0000 Inversion of LP_CanIn4.bIn1_B0...15
• From version 15.00.00
C00401/8 0x0000 Inversion of LP_CanOut4.bOut1_B0...15
• From version 15.00.00
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT
Parameter | Name:
C00407 | LP_CanIn Mapping
Data type: UNSIGNED_32
Index: 24168
d
= 5E68
h
From version 12.00.00
Mapping for port blocks LP_CanIn1...4
• These settings are ORed with the mapping settings for the single words in C00409/x
.
CAN port block
Setting range (min. value | unit | max. value)
0 4294967295
Subcodes Lenze setting Info
C00407/1 0 LP_CanIn1
:dwIn12 MapVal
C00407/2 0 LP_CanIn1
:dwIn34 MapVal
C00407/3 0 LP_CanIn2
:dwIn12 MapVal
C00407/4 0 LP_CanIn2
:dwIn34 MapVal
C00407/5 0 LP_CanIn3
:dwIn12 MapVal
C00407/6 0 LP_CanIn3
:dwIn34 MapVal
C00407/7 0 LP_CanIn4
:dwIn12 MapVal
• From version 15.00.00
C00407/8 0 LP_CanIn4
:dwIn34 MapVal
• From version 15.00.00
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
