Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23 887
15 Parameter reference
15.2 Parameter list
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00386
C00387
C00400
Parameter | Name:
C00386 | CAN HeartBeat ConsumerTime
Data type: UNSIGNED_16
Index: 24189
d
= 5E7D
h
The subcodes represent the nodes to be monitored by heartbeat.
Heartbeat protocol
Setting range (min. value | unit | max. value)
0 ms 60000
Subcodes Lenze setting Info
C00386/1 0 ms ConsumerTime HeartBeat producer 1 ... 15
C00386/...
C00386/15
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00387 | CAN-GatewayAddr
Data type: UNSIGNED_8
Index: 24188
d
= 5E7C
h
From version 12.00.00
CAN gateway
Setting range (min. value | unit | max. value)
0 127
Subcodes Lenze setting Info
C00387/1 0 CAN_Gateway: Addr.
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00400 | LS_PulseGenerator
Data type: UNSIGNED_16
Index: 24175
d
= 5E6F
h
Time setting of the pulse to be output by the SB LS_PulseGenerator
Note:
The real length of the low or high level at the bSquareWave output is always 1 ms higher than set here in subcode
1 or 2. If "0 ms" is set, a level with a length of 1 ms is created length, for instance, and if "1000 ms" is set, a level with
a length of 1001 ms is created.
Setting range (min. value | unit | max. value)
0 ms 60000
Subcodes Lenze setting Info
C00400/1 1000 ms Length of the low level (break) + 1 ms
C00400/2 1000 ms Length of the high level + 1 ms
C00400/3 100 ms From version 06.00.00
Delay time for status signal bFirstCycleDone
•The bFirstCycleDone status signal is set to TRUE when
the first task cycle is complete and the time set here
has expired.
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
