Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23 891
15 Parameter reference
15.2 Parameter list
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00413
C00420
C00423
Parameter | Name:
C00413 | L_SignalMonitor_a: Offs./gain
Data type: INTEGER_16
Index: 24162
d
= 5E62
h
The L_SignalMonitor_a FB: Gain and offset of the analog signals
Setting range (min. value | unit | max. value)
-199.99 % 199.99
Subcodes Lenze setting Info
C00413/1 0.00 % Offset for output nOut1_a
C00413/2 100.00 % Gain for output nOut1_a
C00413/3 0.00 % Offset for output nOut2_a
C00413/4 100.00 % Gain for output nOut2_a
C00413/5 0.00 % Offset for output nOut3_a
C00413/6 100.00 % Gain for output nOut3_a
C00413/7 0.00 % Offset for output nOut4_a
C00413/8 100.00 % Gain for output nOut4_a
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
Parameter | Name:
C00420 | Number of encoder increments
Data type: UNSIGNED_16
Index: 24155
d
= 5E5B
h
Indication of the encoder constant
Encoder/feedback system
Setting range (min. value | unit | max. value)
1 Incr./rev. 32767
Subcodes Lenze setting Info
C00420/1 128 incr./rev. FreqIn12: Encoder increment
C00420/2 128 incr./rev. FreqIn67: Encoder increment
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00423 | DOx: Delay times
Data type: UNSIGNED_16
Index: 24152
d
= 5E58
h
Delay times for the digital output terminals
Digital output terminals
Setting range (min. value | unit | max. value)
0.000 s 65.000
Subcodes Lenze setting Info
C00423/1 0.000 s Relay ON delay
C00423/2 0.000 s Relay OFF delay
C00423/3 0.000 s DO1 ON delay
C00423/4 0.000 s DO1 OFF delay
C00423/5 0.000 s DO2 ON delay
C00423/6 0.000 s DO2 OFF delay
