15 Parameter reference
15.2 Parameter list
892
Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00425
C00434
C00423/7 0.000 s DO3 ON delay
C00423/8 0.000 s DO3 OFF delay
C00423/9 0.000 s DO "High Current" ON delay
C00423/10 0.000 s DO "High Current" OFF delay
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1000
Parameter | Name:
C00423 | DOx: Delay times
Data type: UNSIGNED_16
Index: 24152
d
= 5E58
h
Parameter | Name:
C00425 | Encoder scanning time
Data type: UNSIGNED_8
Index: 24150
d
= 5E56
h
From version 02.00.00
Encoder sample time for the digital input terminals when configured as frequency inputs
Using DI1(6) and DI2(7) as frequency inputs
Selection list
01ms
12 ms
25 ms
310ms
4 20 ms
5 50 ms
6 100 ms
7 200 ms
8 500 ms
9 1000 ms
Subcodes Lenze setting Info
C00425/1 3: 10 ms FreqIn12: Encoder scanning time
• Only active with edge-counting procedure
(C00496
=3).
C00425/2 3: 10 ms FreqIn67: Encoder scanning time
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00434 | OxU/I: Gain
Data type: INTEGER_16
Index: 24141
d
= 5E4D
h
Gain of the analog outputs
Analog terminals
Setting range (min. value | unit | max. value)
-199.99 % 199.99
Subcodes Lenze setting Info
C00434/1 100.00 % O1U: Gain
C00434/2 100.00 % O2U: Gain
C00434/3 100.00 % O1I: Gain
C00434/4 100.00 % O2I: Gain
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
