Lenze 8400 - Page 959

Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23 959
15 Parameter reference
15.2 Parameter list
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00711
Parameter | Name:
C00711 | LA_TabPos: Digital connection list
Data type: UNSIGNED_16
Index: 23864
d
= 5D38
h
Connection parameters for "Table positioning" application: Binary inputs
• Selection of the binary output signals to be connected to the binary input signals
• The selection list contains all binary output signals which can be assigned to the binary inputs mapped by the
subcodes.
Selection list
See selection list - digital signals
Subcodes Lenze setting Info
C00711/1 0: Not connected LA_TabPos
: bCInh
Control input for setting controller inhibit
C00711/2 0: Not connected LA_TabPos
: bFailReset
Control input for error acknowledgement
C00711/3 0: Not connected LA_TabPos
: bSetQuickstop
Control input for quick stop request
C00711/4 0: Not connected LA_TabPos
: bSetSpeedCcw
Control input for negation of speed direction
C00711/5 0: Not connected LA_TabPos
: bJogSpeed1
Control input for fixed speed selection value 1
C00711/6 0: Not connected LA_TabPos
: bJogSpeed2
Control input for fixed speed selection value 2
C00711/7 0: Not connected LA_TabPos
: bMPotEnable
Control input for activation of motor potentiometer
C00711/8 0: Not connected LA_TabPos
: bMPotUp
Control input for motor potentiometer ramp-up
C00711/9 0: Not connected LA_TabPos
: bMPotDown
Control input for motor potentiometer ramp-down
C00711/10 0: Not connected LA_TabPos
: bMBrakeRelease
Control input for manual holding brake release request
C00711/11 0: Not connected LA_TabPos
: bPosCtrlOn
Control input for activation of position controller
C00711/12 0: Not connected LA_TabPos
: bLimitSwitchPos
Input for positive hardware limit switch signal
C00711/13 0: Not connected LA_TabPos
: bLimitSwitchNeg
Input for negative hardware limit switch signal
C00711/14 0: Not connected LA_TabPos
: bReleaseLimitSwitch
Control input for hardware limit switch retracting
request
C00711/15 0: Not connected LA_TabPos
: bManJogPos
Control input for manual jog in positive direction request
C00711/16 0: Not connected LA_TabPos
: bManJogNeg
Control input for manual jog in negative direction
request
C00711/17 0: Not connected LA_TabPos
: bManEnable2ndSpeed
Control input for activation of the second manual speed
for manual jog
C00711/18 0: Not connected LA_TabPos
: bEnableSpeedOverride
Control input for activation of speed override
C00711/19 0: Not connected LA_TabPos
: bEnableAccOverride
Control input for activation of acceleration override
C00711/20 0: Not connected LA_TabPos
: bHomeStartStop
Control input for start/stop homing
