15 Parameter reference
15.2 Parameter list
960
Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00711/21 0: Not connected LA_TabPos: bHomeSetPosition
Control input for setting the home position
C00711/22 0: Not connected LA_TabPos
: bHomeResetPosition
Control input for reset of "Home position known"
C00711/23 0: Not connected LA_TabPos
: bHomeMark
Input for pre-stop signal for homing
C00711/24 0: Not connected LA_TabPos
: bPosSetProfilePosition
Control input for accepting the profile position in the
profile data set
C00711/25 0: Not connected LA_TabPos
: bPosSetActualPosition
Control input for accepting the current position in the
profile data set
C00711/26 0: Not connected LA_TabPos
: bPosExecute
Control input for positioning start
C00711/27 0: Not connected LA_TabPos
: bPosFinishTarget
Control input for completion of positioning to target
position
C00711/28 0: Not connected LA_TabPos
: bPosDisableFollowProfile
Control input for suppression of sequence profile linkage
C00711/29 0: Not connected LA_TabPos
: bPosStop
Control input for interruption of profile generation by
ramp-down procedure
C00711/30 0: Not connected LA_TabPos
: bGPAnalogSwitchSet
Control input for analog-value selector change-over
C00711/31 0: Not connected LA_TabPos
: bGPDigitalDelayIn
Input for digital signal with time delay
C00711/32 0: Not connected LA_TabPos
: bGPLogicIn1
Input signal 1 for digital logic
C00711/33 0: Not connected LA_TabPos
: bGPLogicIn2
Input signal 2 for digital logic
C00711/34 0: Not connected LA_TabPos
: bGPLogicIn3
Input signal 3 for digital logic
C00711/35 0: Not connected LA_TabPos
: bGPDFlipFlop_InD
Control input for DFlipFlop setting signal
C00711/36 0: Not connected LA_TabPos
: bGPDFlipFlop_InClk
Control input for DFlipFlop clock signal
C00711/37 0: Not connected LA_TabPos
: bGPDFlipFlop_InClr
Control input for DFlipFlop reset signal
C00711/38 0: Not connected LA_TabPos
: bGPCounter1ClkUp
Control input for up-counting counter module 1
C00711/39 0: Not connected LA_TabPos
: bGPCounter1ClkDown
Control input for down-counting counter module 1
C00711/40 0: Not connected LA_TabPos
: bGPCounter1Load
Control input for load value acceptance in counter
module 1
C00711/41 0: Not connected LA_TabPos
: bMckOperationMode_1
Control input for MCK operating mode changeover value
1
C00711/42 0: Not connected LA_TabPos
: bMckOperationMode_2
Control input for MCK operating mode changeover value
2
Parameter | Name:
C00711 | LA_TabPos: Digital connection list
Data type: UNSIGNED_16
Index: 23864
d
= 5D38
h
