15 Parameter reference
15.2 Parameter list
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00712
C00711/43 0: Not connected LA_TabPos
: bMckOperationMode_4
Control input for MCK operating mode changeover value
4
C00711/44 0: Not connected LA_TabPos
: bMckOperationMode_8
Control input for MCK operating mode changeover value
8
C00711/45 0: Not connected LA_TabPos
: bPosProfileNo_1
Control input for selection of profile number value 1
C00711/46 0: Not connected LA_TabPos
: bPosProfileNo_2
Control input for selection of profile number value 2
C00711/47 0: Not connected LA_TabPos
: bPosProfileNo_4
Control input for selection of profile number value 4
C00711/48 0: Not connected LA_TabPos
: bPosProfileNo_8
Control input for selection of profile number value 8
C00711/49 0: Not connected LA_TabPos
: bFreeIn1
Input for binary user signal 1
C00711/50 0: Not connected LA_TabPos
: bFreeIn2
Input for binary user signal 2
C00711/51 0: Not connected LA_TabPos
: bFreeIn3
Input for binary user signal 3
C00711/52 0: Not connected LA_TabPos
: bFreeIn4
Input for binary user signal 4
C00711/53 0: Not connected LA_TabPos
: bFreeIn5
Input for binary user signal 5
C00711/54 0: Not connected LA_TabPos
: bFreeIn6
Input for binary user signal 6
C00711/55 0: Not connected LA_TabPos
: bFreeIn7
Input for binary user signal 7
C00711/56 0: Not connected LA_TabPos
: bFreeIn8
Input for binary user signal 8
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00711 | LA_TabPos: Digital connection list
Data type: UNSIGNED_16
Index: 23864
d
= 5D38
h
Parameter | Name:
C00712 | LA_TabPos: phi connection list
Data type: UNSIGNED_16
Index: 23863
d
= 5D37
h
Connection parameters for "Table positioning" application: 32-bit inputs
• Selection of the 32-bit output signals for connection with the 32-bit input signals
• The selection list contains all 32-bit output signals which can be assigned to the 32-bit inputs mapped by the
subcodes.
Selection list
See selection list - angle signals
Subcodes Lenze setting Info
C00712/1 0: Not connected LA_TabPos
: dnPosProfilePosition
Input for selecting the target position in [increments]
C00712/2 0: Not connected LA_TabPos
: dnFreeIn1
Input for 32-bit user signal 1
C00712/3 0: Not connected LA_TabPos
: dnFreeIn2
Input for 32-bit user signal 2
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
