15 Parameter reference
15.2 Parameter list
958
Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00710/10 0: Not connected LA_TabPos: wPosProfileMode
Input for selection of MCK positioning mode in
positioning mode
C00710/11 0: Not connected LA_TabPos
: wPosProfileNo
Input for MCK positioning profile number in positioning
mode
C00710/12 0: Not connected LA_TabPos
: nGPAnalogSwitchIn1_a
Input for analog switch - analog signal 1
C00710/13 0: Not connected LA_TabPos
: nGPAnalogSwitchIn2_a
Input for analog switch - analog signal 2
C00710/14 0: Not connected LA_TabPos
: nGPArithmetikIn1_a
Input for arithmetic function - analog signal 1
C00710/15 0: Not connected LA_TabPos
: nGPArithmetikIn2_a
Input for arithmetic function - analog signal 2
C00710/16 0: Not connected LA_TabPos
: nGPMulDivIn_a
Input for analog signal for multiplication/division
C00710/17 0: Not connected LA_TabPos
: nGPCompareIn1_a
Input for comparison operation - analog signal 1
C00710/18 0: Not connected LA_TabPos
: nGPCompareIn2_a
Input for comparison operation - analog signal 2
C00710/19 0: Not connected LA_TabPos
: wGPCounter1LdVal
Input for load value for counter module 1
C00710/20 0: Not connected LA_TabPos
: wGPCounter1CmpVal
Input for comparison value for counter module 1
C00710/21 0: Not connected LA_TabPos
: nSpeedOverride_a
Input for speed override
C00710/22 0: Not connected LA_TabPos
: nAccOverride_a
Input for acceleration override
C00710/23 0: Not connected LA_TabPos
: wFreeIn1
Input for user signal 1
C00710/24 0: Not connected LA_TabPos
: wFreeIn2
Input for user signal 2
C00710/25 0: Not connected LA_TabPos
: wFreeIn3
Input for user signal 3
C00710/26 0: Not connected LA_TabPos
: wFreeIn4
Input for user signal 4
C00710/27 0: Not connected LA_TabPos
: nPosCtrlOutLimit
Input for correcting variable limitation of position
controller
C00710/28 0: Not connected LA_TabPos
: nPosCtrlPAdapt
Input for adapting the position controller gain
C00710/29 0: Not connected LA_TabPos
: wSMCtrl
Interface to the optional safety system
C00710/30 0: Not connected LA_TabPos
: wPosProfileUnitsLW
Input for selecting the target position in [units], Low-
Word
C00710/31 0: Not connected LA_TabPos
: wPosProfileUnitsHW
Input for selecting the target position in [units], High-
Word
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00710 | LA_TabPos: Analog connection list
Data type: UNSIGNED_16
Index: 23865
d
= 5D39
h
