15 Parameter reference
15.2 Parameter list
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00705
C00706
C00710
C00701/46 0: Not connected LA_NCtrl
: bFreeIn6
Input for binary user signal 6
C00701/47 0: Not connected LA_NCtrl
: bFreeIn7
Input for binary user signal 7
C00701/48 0: Not connected LA_NCtrl
: bFreeIn8
Input for binary user signal 8
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00701 | LA_NCtrl: Digital connection list
Data type: UNSIGNED_16
Index: 23874
d
= 5D42
h
Parameter | Name:
C00705 | LA_NCtrl_Out: Analog signal list
Data type: UNSIGNED_16
Index: 23870
d
= 5D3E
h
This code is for device-internal use only and must not be written to by the user!
Parameter | Name:
C00706 | LA_NCtrl_Out digital signal list
Data type: UNSIGNED_16
Index: 23869
d
= 5D3D
h
This code is for device-internal use only and must not be written to by the user!
Parameter | Name:
C00710 | LA_TabPos: Analog connection list
Data type: UNSIGNED_16
Index: 23865
d
= 5D39
h
Connection parameters for "Table positioning" application: 16-bit inputs
• Selection of the 16 bit output signals to be connected to the 16 bit input signals
• The selection list contains all 16 bit output signals which can be assigned to the 16 bit inputs displayed by the
subcodes.
Selection list
See selection list - analog signals
Subcodes Lenze setting Info
C00710/1 0: Not connected LA_TabPos
: wCanDriveControl
Input for control word from CAN to device control
C00710/2 0: Not connected LA_TabPos
: wMciDriveControl
Input for control word from communication interface to
device control
C00710/3 0: Not connected LA_TabPos
: nTorqueMotLim_a
Input for maximum torque in motor mode
C00710/4 0: Not connected LA_TabPos
: nTorqueGenLim_a
Input for maximum torque in generator mode
C00710/5 0: Not connected LA_TabPos
: nMainSetValue_a
Input for main speed setpoint
C00710/6 0: Not connected LA_TabPos
: nAuxSetValue_a
Input for additional speed setpoint
C00710/7 0: Not connected LA_TabPos
: wMckCtrl1
Input for MCK control word 1
C00710/8 0: Not connected LA_TabPos
: wMckCtrl2
Input for MCK control word 2
C00710/9 0: Not connected LA_TabPos
: wMckOperationMode
Input for selection of MCK operating mode
