15 Parameter reference
15.2 Parameter list
956
Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00701/20 0: Not connected LA_NCtrl: bMBRKRelease
Control input for manual holding brake release request
C00701/21 0: Not connected LA_NCtrl
: bGPFree1
Input for binary user signal
C00701/22 0: Not connected LA_NCtrl
: bGPFree2
Input for binary user signal
C00701/23 0: Not connected LA_NCtrl
: bGPAnalogSwitchSet
Control input for analog-value selector change-over
C00701/24 0: Not connected LA_NCtrl
: bGPDigitalDelayIn
Input for digital signal with time delay
C00701/25 0: Not connected LA_NCtrl
: bGPLogicIn1
Input signal 1 for digital logic
C00701/26 0: Not connected LA_NCtrl
: bGPLogicIn2
Input signal 2 for digital logic
C00701/27 0: Not connected LA_NCtrl
: bGPLogicIn3
Input signal 3 for digital logic
C00701/28 0: Not connected LA_NCtrl
: bGPDFlipFlopInD
Control input for DFlipFlop setting signal
C00701/29 0: Not connected LA_NCtrl
: bGPDFlipFlopInClk
Control input for DFlipFlop clock signal
C00701/30 0: Not connected LA_NCtrl
: bGPDFlipFlopInClr
Control input for DFlipFlop reset signal
C00701/31 0: Not connected LA_NCtrl
: bMPotEnable
Control input for activation of motor potentiometer
C00701/32 0: Not connected LA_NCtrl
: bPIDEnableInfluenceRamp
Control input for activation of influence of output
correcting variable of PID controller
C00701/33 0: Not connected LA_NCtrl
: bPIDIOff
Control input for deactivation of PID controller I
component
C00701/34 20000: LS_ParFix: bTrue LA_NCtrl
: bRLQCw
Control input for activation of CW direction of rotation of
speed setpoint
C00701/35 0: Not connected LA_NCtrl
: bRLQCcw
Control input for activation of CCW direction of rotation
of speed setpoint
C00701/36 0: Not connected Reserved
C00701/37 0: Not connected Reserved
C00701/38 0: Not connected Reserved
C00701/39 0: Not connected Reserved
C00701/40 0: Not connected Reserved
C00701/41 0: Not connected LA_NCtrl
: bFreeIn1
Input for binary user signal 1
C00701/42 0: Not connected LA_NCtrl
: bFreeIn2
Input for binary user signal 2
C00701/43 0: Not connected LA_NCtrl
: bFreeIn3
Input for binary user signal 3
C00701/44 0: Not connected LA_NCtrl
: bFreeIn4
Input for binary user signal 4
C00701/45 0: Not connected LA_NCtrl
: bFreeIn5
Input for binary user signal 5
Parameter | Name:
C00701 | LA_NCtrl: Digital connection list
Data type: UNSIGNED_16
Index: 23874
d
= 5D42
h
