C00701
Parameter | Name:
C00701 | LA_NCtrl: Digital connection list
Data type: UNSIGNED_16
Index: 23874
d
= 5D42
h
Connection parameters for "Actuating drive speed" application: Binary inputs
• Selection of the binary output signals to be connected to the binary input signals
• The selection list contains all binary output signals which can be assigned to the binary inputs mapped by the
subcodes.
Selection list
See selection list - digital signals
Subcodes Lenze setting Info
C00701/1 0: Not connected LA_NCtrl
: bCInh
Control input for setting controller inhibit
C00701/2 16008: LS_DigitalInput: bCInh LA_NCtrl
: bFailReset
Control input for error acknowledgement
C00701/3 0: Not connected LA_NCtrl
: bSetQuickstop
Control input for quick stop request
C00701/4 16002: LS_DigitalInput: bIn3 LA_NCtrl
: bSetDCBrake
Control input for DC-injection braking request
C00701/5 0: Not connected LA_NCtrl
: bRFG_Stop
Control input for stopping the speed ramp function
generator
C00701/6 0: Not connected LA_NCtrl
: bRFG_0
Control input for setting the speed ramp function
generator to 0
C00701/7 0: Not connected Reserved
C00701/8 16003: LS_DigitalInput: bIn4 LA_NCtrl
: bSetSpeedCcw
Control input for change of direction of rotation
C00701/9 16000: LS_DigitalInput: bIn1 LA_NCtrl
: bJogSpeed1
Selection input for fixed setpoints
C00701/10 16001: LS_DigitalInput: bIn2 LA_NCtrl
: bJogSpeed2
Selection input for fixed setpoints
C00701/11 0: Not connected LA_NCtrl
: bJogSpeed4
Selection input for fixed setpoints
C00701/12 0: Not connected LA_NCtrl
: bJogSpeed8
Selection input for fixed setpoints
C00701/13 0: Not connected LA_NCtrl
: bJogRamp1
Selection input for additional acceleration/deceleration
times
C00701/14 0: Not connected LA_NCtrl
: bJogRamp2
Selection input for additional acceleration/deceleration
times
C00701/15 0: Not connected LA_NCtrl
: bJogRamp4
Selection input for additional acceleration/deceleration
times
C00701/16 0: Not connected LA_NCtrl
: bJogRamp8
Selection input for additional acceleration/deceleration
times
C00701/17 0: Not connected LA_NCtrl
: bMPOTInAct
Control input for deactivation of motor potentiometer
C00701/18 0: Not connected LA_NCtrl
: bMPOTUp
Control input for motor potentiometer ramp-up
C00701/19 0: Not connected LA_NCtrl
: bMPOTDown
Control input for motor potentiometer ramp-down
