Lenze 8400 - Page 954

15 Parameter reference
15.2 Parameter list
954
Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00700/6 0: Not connected LA_NCtrl: nPIDActValue_a
Input for actual PID controller value
C00700/7 16000: LS_AnalogInput: nIn1_a LA_NCtrl
: nMainSetValue_a
Input for main speed setpoint
C00700/8 0: Not connected LA_NCtrl
: nAuxSetValue_a
Input for additional speed setpoint
C00700/9 0: Not connected LA_NCtrl
: nGPAnalogSwitchIn1_a
Input for analog switch - analog signal 1
C00700/10 0: Not connected LA_NCtrl
: nGPAnalogSwitchIn2_a
Input for analog switch - analog signal 2
C00700/11 0: Not connected LA_NCtrl
: nGPArithmetikIn1_a
Input for arithmetic function - analog signal 1
C00700/12 0: Not connected LA_NCtrl
: nGPArithmetikIn2_a
Input for arithmetic function - analog signal 2
C00700/13 0: Not connected LA_NCtrl
: nGPMulDivIn_a
Input for analog signal for multiplication/division
C00700/14 0: Not connected LA_NCtrl
: nGPCompareIn1_a
Input for comparison operation - analog signal 1
C00700/15 0: Not connected LA_NCtrl
: nGPCompareIn2_a
Input for comparison operation - analog signal 2
C00700/16 0: Not connected LA_NCtrl
: nVoltageAdd_a
Input for additive voltage boost
C00700/17 0: Not connected LA_NCtrl
: nPIDInfluence_a
Input for influence signal of PID controller correcting
variable
C00700/18 0: Not connected LA_NCtrl
: nPIDSetValue_a
Input for PID controller setpoint
C00700/19 0: Not connected LA_NCtrl
: nPWMAngleOffset
Input for pulse width modulation phase offset
C00700/20 0: Not connected LA_NCtrl
: nBoost_a
Input for additional setpoint for motor voltage at speed
= 0
C00700/21 0: Not connected LA_NCtrl
: wSMCtrl
Interface to the optional safety system
C00700/22 0: Not connected Reserved
C00700/23 0: Not connected Reserved
C00700/24 0: Not connected Reserved
C00700/25 0: Not connected Reserved
C00700/26 0: Not connected LA_NCtrl
: wFreeIn1
Input for user signal 1
C00700/27 0: Not connected LA_NCtrl
: wFreeIn2
Input for user signal 2
C00700/28 0: Not connected LA_NCtrl
: wFreeIn3
Input for user signal 3
C00700/29 0: Not connected LA_NCtrl
: wFreeIn4
Input for user signal 4
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00700 | LA_NCtrl: Analog connection list
Data type: UNSIGNED_16
Index: 23875
d
= 5D43
h
