Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23 953
15 Parameter reference
15.2 Parameter list
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00697
C00698
C00699
C00700
Parameter | Name:
C00697 | L_OffsetGainP_2: Offset
Data type: INTEGER_16
Index: 23878
d
= 5D46
h
The L_OffsetGainP_2 FB: Offset (additive to the input signal)
Setting range (min. value | unit | max. value) Lenze setting
-199.99 % 199.99 0.00 %
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
Parameter | Name:
C00698 | L_OffsetGainP_3: Offset
Data type: INTEGER_16
Index: 23877
d
= 5D45
h
The L_OffsetGainP_3 FB: Offset (additive to the input signal)
Setting range (min. value | unit | max. value) Lenze setting
-199.99 % 199.99 0.00 %
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
Parameter | Name:
C00699 | L_MulDiv_1: Parameter
Data type: INTEGER_16
Index: 23876
d
= 5D44
h
The L_MulDiv_1 FB: Numerator and denominator
Setting range (min. value | unit | max. value)
-32767 32767
Subcodes Lenze setting Info
C00699/1 0 L_MulDiv_1
: Numerator
C00699/2 10000 L_MulDiv_1
: Denominator
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00700 | LA_NCtrl: Analog connection list
Data type: UNSIGNED_16
Index: 23875
d
= 5D43
h
Connection parameters for "Actuating drive speed" application: 16-bit inputs
• Selection of the 16 bit output signals to be connected to the 16 bit input signals
• The selection list contains all 16 bit output signals which can be assigned to the 16 bit inputs displayed by the
subcodes.
Selection list
See selection list - analog signals
Subcodes Lenze setting Info
C00700/1 20005: LS_ParFix: wDriveCtrl LA_NCtrl
: wCANDriveControl
Input for control word from CAN to device control
C00700/2 20005: LS_ParFix: wDriveCtrl LA_NCtrl
: wMCIDriveControl
Input for control word from communication interface to
device control
C00700/3 20012: LS_ParFree_a: nC472_3_a LA_NCtrl
: nTorqueMotLim_a
Input for maximum torque in motor mode
C00700/4 20013: LS_ParFree_a: nC472_4_a LA_NCtrl
: nTorqueGenLim_a
Input for maximum torque in generator mode
C00700/5 0: Not connected LA_NCtrl
: nPIDVpAdapt_a
Input for adapting the PID controller gain
