Lenze 8400 - Page 952

15 Parameter reference
15.2 Parameter list
952
Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00693
C00694
C00695
C00696
Parameter | Name:
C00693 | L_Compare 4-5: Function
Data type: UNSIGNED_8
Index: 23882
d
= 5D4A
h
Comparison operation
• If the statement of the selected comparison operation is true, the binary bOut output will be set to TRUE.
Selection list
1In1 = In2
2In1 > In2
3In1 < In2
4 |In1| = |In2|
5 |In1| > |In2|
6 |In1| < |In2|
Subcodes Lenze setting Info
C00693/1 1: In1 = In2 L_Compare_4
: Function
C00693/2 1: In1 = In2 L_Compare_5
: Function
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00694 | L_Compare 4-5: Hysteresis
Data type: INTEGER_16
Index: 23881
d
= 5D49
h
Hysteresis for the comparison operation selected in C00693
Setting range (min. value | unit | max. value)
0.00 % 100.00
Subcodes Lenze setting Info
C00694/1 0.00 % L_Compare_4
: Hysteresis
C00694/2 0.00 % L_Compare_5
: Hysteresis
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
Parameter | Name:
C00695 | L_Compare 4-5: Window
Data type: INTEGER_16
Index: 23880
d
= 5D48
h
Window for the comparison operation selected in C00693
Setting range (min. value | unit | max. value)
0.00 % 100.00
Subcodes Lenze setting Info
C00695/1 0.00 % L_Compare_4
: Window
C00695/2 0.00 % L_Compare_5
: Window
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
Parameter | Name:
C00696 | L_OffsetGainP_1: Offset
Data type: INTEGER_16
Index: 23879
d
= 5D47
h
The L_OffsetGainP_1 FB: Offset (additive to the input signal)
Setting range (min. value | unit | max. value) Lenze setting
-199.99 % 199.99 0.00 %
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
