Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23 951
15 Parameter reference
15.2 Parameter list
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00686
C00687
C00690
C00691
C00692
Parameter | Name:
C00686 | L_Compare_2: Hysteresis
Data type: INTEGER_16
Index: 23889
d
= 5D51
h
The L_Compare_2 FB: Hysteresis for the comparison function selected in C00685
Setting range (min. value | unit | max. value) Lenze setting
0.00 % 100.00 0.50 %
Read access Write access CINH PLC STOP No transfer COM MOT Scaling factor: 100
Parameter | Name:
C00687 | L_Compare_2: Window
Data type: INTEGER_16
Index: 23888
d
= 5D50
h
The L_Compare_2 FB: Window for the comparison function selected in C00685
Setting range (min. value | unit | max. value) Lenze setting
0.00 % 100.00 2.00 %
Read access Write access CINH PLC STOP No transfer COM MOT Scaling factor: 100
Parameter | Name:
C00690 | L_Compare_3: Function
Data type: UNSIGNED_8
Index: 23885
d
= 5D4D
h
The L_Compare_3 FB: Comparison operation
If the statement of the selected comparison operation is true, the binary bOut output will be set to TRUE.
Selection list (Lenze setting printed in bold)
1In1 = In2
2In1 > In2
3In1 < In2
4 |In1| = |In2|
5 |In1| > |In2|
6 |In1| < |In2|
Read access Write access CINH PLC STOP No transfer COM MOT Scaling factor: 1
Parameter | Name:
C00691 | L_Compare_3: Hysteresis
Data type: INTEGER_16
Index: 23884
d
= 5D4C
h
FB L_Compare_3: Hysteresis for the comparison operation selected in C00690
Setting range (min. value | unit | max. value) Lenze setting
0.00 % 100.00 0.00 %
Read access Write access CINH PLC STOP No transfer COM MOT Scaling factor: 100
Parameter | Name:
C00692 | L_Compare_3: Window
Data type: INTEGER_16
Index: 23883
d
= 5D4B
h
FB L_Compare_3: window for the comparison operation selected in C00690
Setting range (min. value | unit | max. value) Lenze setting
0.00 % 100.00 0.00 %
Read access Write access CINH PLC STOP No transfer COM MOT Scaling factor: 100
