15 Parameter reference
15.2 Parameter list
968
Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00761
Parameter | Name:
C00761 | LA_SwitchPos: Digital connection list
Data type: UNSIGNED_16
Index: 23814
d
= 5D06
h
Connection parameters for "Switch-off positioning" application: Binary inputs
• Selection of the binary output signals to be connected to the binary input signals
• The selection list contains all binary output signals which can be assigned to the binary inputs mapped by the
subcodes.
Selection list
See selection list - digital signals
Subcodes Lenze setting Info
C00761/1 0: Not connected LA_SwitchPos
: bCInh
Control input for setting controller inhibit
C00761/2 0: Not connected LA_SwitchPos
: bFailReset
Control input for error acknowledgement
C00761/3 0: Not connected LA_SwitchPos
: bSetQuickstop
Control input for quick stop request
C00761/4 0: Not connected LA_SwitchPos
: bSetDCBrake
Control input for DC-injection braking request
C00761/5 0: Not connected LA_SwitchPos
: bRFG_Stop
Control input for stopping the speed ramp function
generator
C00761/6 0: Not connected LA_SwitchPos
: bSetSpeedCcw
Control input for change of direction of rotation
C00761/7 0: Not connected LA_SwitchPos
: bRLQCw
Control input for activation of CW rotation (fail-safe)
C00761/8 0: Not connected LA_SwitchPos
: bRLQCcw
Control input for activation of CCW rotation (fail-safe)
C00761/9 0: Not connected LA_SwitchPos
: bJogCtrlInputSel1
Selection input 1 for binary coded selection of the
switch-off position 1 ... 3
C00761/10 0: Not connected LA_SwitchPos
: bJogCtrlInputSel2
Selection input 2 for binary coded selection of the
switch-off position 1 ... 3
C00761/11 0: Not connected LA_SwitchPos
: bJogCtrlRfgIn
Control input for setpoint generator ramp-down
C00761/12 0: Not connected LA_SwitchPos
: bJogCtrlJog1
Selection input 1 for overriding fixed setpoints (JOG
setpoints) for the main setpoint
C00761/13 0: Not connected LA_SwitchPos
: bJogCtrlJog2
Selection input 2 for overriding fixed setpoints (JOG
setpoints) for the main setpoint
C00761/14 0: Not connected LA_SwitchPos
: bJogCtrlSlowDown1
Control input for selection of pre-switch off 1
C00761/15 0: Not connected LA_SwitchPos
: bJogCtrlStop1
Control input for stop function 1
C00761/16 0: Not connected LA_SwitchPos
: bJogCtrlSlowDown2
Control input for selection of pre-switch off 2
C00761/17 0: Not connected LA_SwitchPos
: bJogCtrlStop2
Control input for stop function 2
C00761/18 0: Not connected LA_SwitchPos
: bJogCtrlSlowDown3
Control input for selection of pre-switch off 3
C00761/19 0: Not connected LA_SwitchPos
: bJogCtrlStop3
Control input for stop function 3
