Lenze 8400 - Page 967

Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23 967
15 Parameter reference
15.2 Parameter list
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00760/1 0: Not connected LA_SwitchPos: wCANDriveControl
Input for control word from CAN to device control
C00760/2 0: Not connected LA_SwitchPos
: wMCIDriveControl
Input for control word from communication interface to
device control
C00760/3 0: Not connected LA_SwitchPos
: nVoltageAdd_a
Input for additive voltage impression
C00760/4 0: Not connected LA_SwitchPos
: nBoost_a
Input for additional setpoint for motor voltage at speed
= 0
C00760/5 0: Not connected LA_SwitchPos
: nPWMAngleOffset
Input for additional offset for the electrical angle of
rotation
C00760/6 0: Not connected LA_SwitchPos
: nTorqueMotLim_a
Input for maximum torque in motor mode
C00760/7 0: Not connected LA_SwitchPos
: nTorqueGenLim_a
Input for maximum torque in generator mode
C00760/8 0: Not connected LA_SwitchPos
: nMainSetValue_a
Input for main speed setpoint
C00760/9 0: Not connected LA_SwitchPos
: nAuxSetValue_a
Input for additional speed setpoint
C00760/10 0: Not connected LA_SwitchPos
: nGPAnalogSwitchIn1_a
Input for analog switch - analog signal 1
C00760/11 0: Not connected LA_SwitchPos
: nGPAnalogSwitchIn2_a
Input for analog switch - analog signal 2
C00760/12 0: Not connected LA_SwitchPos
: nGPArithmetikIn1_a
Input for arithmetic function - analog signal 1
C00760/13 0: Not connected LA_SwitchPos
: nGPArithmetikIn2_a
Input for arithmetic function - analog signal 2
C00760/14 0: Not connected LA_SwitchPos
: nGPMulDivIn_a
Input for analog signal for multiplication/division
C00760/15 0: Not connected LA_SwitchPos
: nGPCompareIn1_a
Input for comparison operation - analog signal 1
C00760/16 0: Not connected LA_SwitchPos
: nGPCompareIn2_a
Input for comparison operation - analog signal 2
C00760/17 0: Not connected LA_SwitchPos
: wSMCtrl
Interface to the optional safety system
C00760/18 0: Not connected Reserved
C00760/19 0: Not connected Reserved
C00760/20 0: Not connected Reserved
C00760/21 0: Not connected Reserved
C00760/22 0: Not connected LA_SwitchPos
: wFreeIn1
Input for user signal 1
C00760/23 0: Not connected LA_SwitchPos
: wFreeIn2
Input for user signal 2
C00760/24 0: Not connected LA_SwitchPos
: wFreeIn3
Input for user signal 3
C00760/25 0: Not connected LA_SwitchPos
: wFreeIn4
Input for user signal 4
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00760 | LA_SwitchPos: Analog connection list
Data type: UNSIGNED_16
Index: 23815
d
= 5D07
h
