Lenze 8400 - Page 966

15 Parameter reference
15.2 Parameter list
966
Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00746
C00747
C00748
C00749
C00750
C00751
C00753
C00760
Parameter | Name:
C00746 | Oscilloscope trigger counter
Data type: UNSIGNED_32
Index: 23829
d
= 5D15
h
This code is for device-internal use only and must not be written to by the user!
Parameter | Name:
C00747 | Oscilloscope status word
Data type: UNSIGNED_16
Index: 23828
d
= 5D14
h
This code is for device-internal use only and must not be written to by the user!
Parameter | Name:
C00748 | Oscilloscope no. of measured values
Data type: UNSIGNED_32
Index: 23827
d
= 5D13
h
This code is for device-internal use only and must not be written to by the user!
Parameter | Name:
C00749 | Oscilloscope recording
Data type: UNSIGNED_32
Index: 23826
d
= 5D12
h
This code is for device-internal use only and must not be written to by the user!
Parameter | Name:
C00750 | Select. of MCTRL oscillos. channels
Data type: UNSIGNED_8
Index: 23825
d
= 5D11
h
This code is for device-internal use only and must not be written to by the user!
Parameter | Name:
C00751 | Oscilloscope data memory
Data type: UNSIGNED_32
Index: 23824
d
= 5D10
h
This code is for device-internal use only and must not be written to by the user!
Parameter | Name:
C00753 | Oscilloscope data memory octet string
Data type: OCTET_STRING
Index: 23822
d
= 5D0E
h
This code is for device-internal use only and must not be written to by the user!
Parameter | Name:
C00760 | LA_SwitchPos: Analog connection list
Data type: UNSIGNED_16
Index: 23815
d
= 5D07
h
Connection parameters for "Switch-off positioning" application: 16-bi inputs
• Selection of the 16 bit output signals to be connected to the 16 bit input signals
• The selection list contains all 16 bit output signals which can be assigned to the 16 bit inputs displayed by the
subcodes.
Selection list
See selection list - analog signals
Subcodes Lenze setting Info
