Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23 969
15 Parameter reference
15.2 Parameter list
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00761/20 0: Not connected LA_SwitchPos: bJogSpeed4
Selection input for fixed setpoints
C00761/21 0: Not connected LA_SwitchPos
: bJogSpeed8
Selection input for fixed setpoints
C00761/22 0: Not connected LA_SwitchPos
: bJogRamp1
Selection input for additional acceleration/deceleration
times
C00761/23 0: Not connected LA_SwitchPos
: bJogRamp2
Selection input for additional acceleration/deceleration
times
C00761/24 0: Not connected LA_SwitchPos
: bJogRamp4
Selection input for additional acceleration/deceleration
times
C00761/25 0: Not connected LA_SwitchPos
: bJogRamp8
Selection input for additional acceleration/deceleration
times
C00761/26 0: Not connected LA_SwitchPos
: bMBrkRelease
Control input for manual holding brake release request
C00761/27 0: Not connected LA_SwitchPos
: bGPAnalogSwitchSet
Control input for analog-value selector change-over
C00761/28 0: Not connected LA_SwitchPos
: bGPDigitalDelayIn
Input for digital signal with time delay
C00761/29 0: Not connected LA_SwitchPos
: bGPLogicIn1
Input signal 1 for digital logic
C00761/30 0: Not connected LA_SwitchPos
: bGPLogicIn2
Input signal 2 for digital logic
C00761/31 0: Not connected LA_SwitchPos
: bGPLogicIn3
Input signal 3 for digital logic
C00761/32 0: Not connected LA_SwitchPos
: bGPDFlipFlop_InD
Control input for DFlipFlop setting signal
C00761/33 0: Not connected LA_SwitchPos
: bGPDFlipFlop_InClk
Control input for DFlipFlop clock signal
C00761/34 0: Not connected LA_SwitchPos
: bGPDFlipFlop_InClr
Control input for DFlipFlop reset signal
C00761/35 0: Not connected Reserved
C00761/36 0: Not connected Reserved
C00761/37 0: Not connected Reserved
C00761/38 0: Not connected Reserved
C00761/39 0: Not connected Reserved
C00761/40 0: Not connected LA_SwitchPos
: bFreeIn1
Input for binary user signal 1
C00761/41 0: Not connected LA_SwitchPos
: bFreeIn2
Input for binary user signal 2
C00761/42 0: Not connected LA_SwitchPos
: bFreeIn3
Input for binary user signal 3
C00761/43 0: Not connected LA_SwitchPos
: bFreeIn4
Input for binary user signal 4
C00761/44 0: Not connected LA_SwitchPos
: bFreeIn5
Input for binary user signal 5
C00761/45 0: Not connected LA_SwitchPos
: bFreeIn6
Input for binary user signal 6
Parameter | Name:
C00761 | LA_SwitchPos: Digital connection list
Data type: UNSIGNED_16
Index: 23814
d
= 5D06
h
