15 Parameter reference
15.2 Parameter list
970
Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00762
C00765
C00766
C00767
C00800
C00801
C00761/46 0: Not connected LA_SwitchPos
: bFreeIn7
Input for binary user signal 7
C00761/47 0: Not connected LA_SwitchPos
: bFreeIn8
Input for binary user signal 8
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00761 | LA_SwitchPos: Digital connection list
Data type: UNSIGNED_16
Index: 23814
d
= 5D06
h
Parameter | Name:
C00762 | LA_SwitchPos: phi connection list
Data type: UNSIGNED_16
Index: 23813
d
= 5D05
h
This code is for device-internal use only and must not be written to by the user!
Parameter | Name:
C00765 | LA_SwitchPos_Out: Analog signal list
Data type: UNSIGNED_16
Index: 23810
d
= 5D02
h
This code is for device-internal use only and must not be written to by the user!
Parameter | Name:
C00766 | LA_SwitchPos_Out: Digital signal list
Data type: UNSIGNED_16
Index: 23809
d
= 5D01
h
This code is for device-internal use only and must not be written to by the user!
Parameter | Name:
C00767 | LA_SwitchPos_Out: phi signal list
Data type: UNSIGNED_16
Index: 23808
d
= 5D00
h
This code is for device-internal use only and must not be written to by the user!
Parameter | Name:
C00800 | L_MPot_1: Upper limit
Data type: INTEGER_16
Index: 23775
d
= 5CDF
h
The L_MPot_1 FB: Upper limit of the motor potentiometer function
Setting range (min. value | unit | max. value) Lenze setting
-199.99 % 199.99 100.00 %
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
Parameter | Name:
C00801 | L_MPot_1: Lower limit
Data type: INTEGER_16
Index: 23774
d
= 5CDE
h
The L_MPot_1 FB: Lower limit of the motor potentiometer function
Setting range (min. value | unit | max. value) Lenze setting
-199.99 % 199.99 -100.00 %
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
