15 Parameter reference
15.2 Parameter list
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00114
C00115
Parameter | Name:
C00114 | DigInX: Inversion
Data type: UNSIGNED_16
Index: 24461
d
= 5F8D
h
The polarity of each digital input of the device can be inverted via this bit field.
Digital input terminals
Setting range (min. hex value | max. hex value) Lenze setting
0x0000 0xFFFF 0x0000 (decimal: 0)
Value is bit-coded: ( =bit set) Info
Bit 0  DI1 inverted Inversion of digital input 1
Bit 1  DI2 inverted Inversion of digital input 2
Bit 2  DI3 inverted Inversion of digital input 3
Bit 3  DI4 inverted Inversion of digital input 4
Bit 4  DI5 inverted Inversion of digital input 5
Bit 5  DI6 inverted Inversion of digital input 6
Bit 6  DI7 inverted Inversion of digital input 7
Bit 7  Reserved
Bit 8  Reserved
Bit 9  Reserved
Bit 10  Reserved
Bit 11  Reserved
Bit 12  Reserved
Bit 13  Reserved
Bit 14  Reserved
Bit 15  CInh inverted Inversion of digital input RFR (controller enable)
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT
Parameter | Name:
C00115 | DI 1/2 & 6/7: Fct.
Data type: UNSIGNED_8
Index: 24460
d
= 5F8C
h
Function assignment of the digital terminals DI1/2 and DI6/7
Digital input terminals
: Function assignment
Selection list Info
0 DI1(6)=In / DI2(7)=In DI1/6 = digital input
DI2/7 = digital input
1 DI1(6)=FreqIn / DI2(7)=In DI1/6 = 1-track frequency input
DI2/7 = digital input
2 DI1(6)&DI2(7)=FreqIn (2-track) DI1/6 and DI2/7 = 2-track frequency input
3 DI1(6)=FreqIn / DI2(7)=direction DI1/6 = 1-track frequency input
DI2/7 = specification of direction
4 DI1(6)=CountIn / DI2(7)=In DI1/6 = counter input
DI2/7 = digital input
Subcodes Lenze setting Info
C00115/1 0: DI1(6)=In / DI2(7)=In Function assignment of DI1 and DI2
C00115/2 0: DI1(6)=In / DI2(7)=In Function assignment of DI6 and DI7
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
