15 Parameter reference
15.2 Parameter list
838
Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00117
C00118
C00120
Parameter | Name:
C00117 | Status of brake output BD
Data type: UNSIGNED_8
Index: 24458
d
= 5F8A
h
Status message of brake output
Selection list (read only) Info
0 Inactive Brake output is inactive
1 Active Brake output is active
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00118 | DigOutX: Inversion
Data type: UNSIGNED_8
Index: 24457
d
= 5F89
h
The polarity of each digital output of the device can be inverted via this bit field.
Digital output terminals
Setting range (min. hex value | max. hex value) Lenze setting
0x00 0xFF 0x00 (decimal: 0)
Value is bit-coded: ( =bit set) Info
Bit 0  Relay inverted Relay inversion
Bit 1  DO1 inverted Inversion of digital output 1
Bit 2  DO2 inverted Inversion of digital output 2
Bit 3  DO3 inverted Inversion of digital output 3
Bit 4  High current inverted Inversion of high-current output
Bit 5  Reserved
Bit 6  Reserved
Bit 7  Reserved
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT
Parameter | Name:
C00120 | Setting of motor overload (I²xt)
Data type: INTEGER_16
Index: 24455
d
= 5F87
h
Operating threshold for the "OC6: Motor overload (I²xt)" error message
• The response for reaching the threshold can be selected in C00606
.
• The current thermal motor load is displayed in C00066
.
Motor overload monitoring (I2xt)
Setting range (min. value | unit | max. value) Lenze setting
0.00 % 250.00 100.00 %
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
