Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23 827
15 Parameter reference
15.2 Parameter list
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00064
C00065
C00066
C00070
Parameter | Name:
C00064 | Device utilisation (Ixt)
Data type: INTEGER_16
Index: 24511
d
= 5FBF
h
Display of the device utilisation Ixt in different time resolutions
• If the value displayed here exceeds the threshold set in C00123
, the fault message "OC5: Device overload (Ixt)"
is output and the fault response set in C00604
is executed (default setting: "Warning").
Display range (min. value | unit | max. value)
0.00 % 250.00
Subcodes Info
C00064/1 Device utilisation (Ixt)
• Maximum value of the pulse utilisation (C00064/2)
and permanent utilisation (C00064/3).
C00064/2 Device utilisation (Ixt) 15s
• Pulse utilisation over the last 15 seconds (only for
loads >160 %).
C00064/3 Device utilisation (Ixt) 3 min
• Permanent utilisation over the last 3 minutes.
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
Parameter | Name:
C00065 | Supply voltage 24V
Data type: INTEGER_16
Index: 24510
d
= 5FBE
h
Display of the 24V supply voltage for the supply of the control electronics
Note:
The 24 V supply for the control electronics is either provided by an external supply or by the invter itself if it is
connected to the mains voltage.
Display range (min. value | unit | max. value)
0.0 V 3276.7
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 10
Parameter | Name:
C00066 | Thermal motor load (I²xt)
Data type: INTEGER_16
Index: 24509
d
= 5FBD
h
Display of the thermal motor load, sensorlessly determined using a motor model
• If the value displayed here exceeds "100.00 %", the error message "OC6: Thermal motor overload (I2xt)" is output
and the fault response set in C00606
is executed (default setting: "Warning").
Motor overload monitoring (I2xt)
Display range (min. value | unit | max. value)
0.00 % 199.99
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
Parameter | Name:
C00070 | Vp speed controller
Data type: UNSIGNED_16
Index: 24505
d
= 5FB9
h
Gain factor Vp of the speed controller for different motor control types
Setting range (min. value | unit | max. value)
0.00 600.00
