Lenze 8400 - Page 828

15 Parameter reference
15.2 Parameter list
828
Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00071
C00072
C00073
Subcodes Lenze setting Info
C00070/1 power-related (see table
) SLVC: Vp speed controller
C00070/2 power-related (see table
) SC: Vp speed controller
C00070/3 power-related (see table
) SLPSM: Vp speed controller
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
Parameter | Name:
C00070 | Vp speed controller
Data type: UNSIGNED_16
Index: 24505
d
= 5FB9
h
Parameter | Name:
C00071 | Ti speed controller
Data type: UNSIGNED_16
Index: 24504
d
= 5FB8
h
Reset time Ti of the speed controller for different motor control types
Setting range (min. value | unit | max. value)
0.0 ms 6000.0
Subcodes Lenze setting Info
C00071/1 100.0 ms SLVC
: Ti speed controller
C00071/2 50.0 ms SC
: Ti speed controller
C00071/3 50.0 ms SLPSM
: Ti speed controller
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 10
Parameter | Name:
C00072 | SC: Tdn speed controller
Data type: UNSIGNED_16
Index: 24503
d
= 5FB7
h
Differential time constant Tdn of the speed controller for servo control (SC) and sensorless control for synchronous
motors (SLPSM
)
Setting range (min. value | unit | max. value) Lenze setting
0.00 ms 3.00 0.00 ms
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
Parameter | Name:
C00073 | Imax/M controller gain
Data type: UNSIGNED_16
Index: 24502
d
= 5FB6
h
Amplification factor Vp of certain controllers for different motor control modes
Setting range (min. value | unit | max. value)
0.00 100.00
Subcodes Lenze setting Info
C00073/1 power-related (see table
) VFC: Vp Imax controller
• After the motor to be used has been selected from the
motor catalogue, the suitable value can be entered
automatically.
C00073/2 power-related (see table
) SLVC: Vp torque controller
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
