Lenze 8400 - Page 929

Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23 929
15 Parameter reference
15.2 Parameter list
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00605
C00606
C00607
C00608
Parameter | Name:
C00605 | Resp. to feedback
Data type: UNSIGNED_8
Index: 23970
d
= 5DA2
h
From version 15.00.00
Selection list
0 No Reaction
1Fault
2Trouble
3 TroubleQuickStop
4 WarningLocked
5 Warning
6 Information
Subcodes Lenze setting Info
C00605/1 1: Fault Resp. to open circuit HTL 4-fold
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00606 | Resp. to motor overload (I²xt)
Data type: UNSIGNED_8
Index: 23969
d
= 5DA1
h
Response when the motor load displayed in C00066 reaches the value "100.00 %".
Motor overload monitoring (I2xt)
Selection list (Lenze setting printed in bold)
0 No Reaction
1Fault
5 Warning
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00607 | Resp. to max freq. feedb. DIG12/67
Data type: UNSIGNED_8
Index: 23968
d
= 5DA0
h
Response when the maximum input frequency has been reached via the digital inputs.
Selection list (Lenze setting printed in bold)
0 No Reaction
1Fault
5 Warning
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00608 | Resp. to maximum torque
Data type: UNSIGNED_8
Index: 23967
d
= 5D9F
h
Response if the maximum torque (C00057) is reached.
Selection list (Lenze setting printed in bold)
0No Reaction
1Fault
5 Warning
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
