15 Parameter reference
15.2 Parameter list
836
Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00105
C00106
C00107
Bit 13 Reserved
Bit 14 Reserved
Bit 15 Reserved
Subcodes Lenze setting Info
C00104/1 0x0000 Quick stop setting
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT
Parameter | Name:
C00104 | Quick stop setting
Data type: UNSIGNED_16
Index: 24471
d
= 5F97
h
Parameter | Name:
C00105 | Decel. time - quick stop
Data type: UNSIGNED_32
Index: 24470
d
= 5F96
h
The set deceleration time determines the ramp slope at quick stop
Activate/deactivate quick stop
Setting range (min. value | unit | max. value) Lenze setting
0.000 s 999.900 2.000 s
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1000
Parameter | Name:
C00106 | Auto DCB: Hold time
Data type: UNSIGNED_32
Index: 24469
d
= 5F95
h
Hold time of the automatic DC injection brake
• The DC injection brake is applied for the time set here if the value falls below the speed setpoint set in C00019
.
DC-injection braking
Setting range (min. value | unit | max. value) Lenze setting
0.000 s 999.000 0.500 s
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1000
Parameter | Name:
C00107 | DC braking: Hold time
Data type: UNSIGNED_32
Index: 24468
d
= 5F94
h
Maximum hold time of the manual DC injection brake
• A time can be set here after which the DC injection brake is switched off automatically to prevent the motor from
thermal overload.
• When "999.000 s" is set, the hold time is infinite.
DC-injection braking
Setting range (min. value | unit | max. value) Lenze setting
0.000 s 999.000 999.000 s
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1000
