15 Parameter reference
15.2 Parameter list
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00103
C00104
Parameter | Name:
C00103 | Add. decel. time x
Data type: UNSIGNED_32
Index: 24472
d
= 5F98
h
The L_NSet_1 FB: Additional deceleration times for the main setpoint
• The additional deceleration times set here can be selected via the binary inputs bTI1 ... bTI8 of the L_NSet_1
FB.
Setting range (min. value | unit | max. value)
0.000 s 999.999
Subcodes Lenze setting Info
C00103/1 0.000 s Add. decel. time 1 ... 15
C00103/...
C00103/15
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1000
Parameter | Name:
C00104 | Quick stop setting
Data type: UNSIGNED_16
Index: 24471
d
= 5F97
h
From version 10.00.00
Quick stop: Optional settings
Setting range (min. hex value | max. hex value)
0x0000 0xFFFF
Value is bit-coded: Info
Bit 0 Standstill position-controlled 1 ≡ At standstill the position control is activated.
The basic conditions are shown in the flow diagram
for
the quick stop function.
Bit 1 Ramp position-controlled 1 ≡ During the ramp-down phase, the position control is
activated.
The basic conditions are shown in the flow diagram
for
the quick stop function.
Bit 2 Continue following error From version 15.00.00
1 ≡ The current following error is continued if the quick
stop with position control is activated while ramping
down.
Bit 3 Starting value is the setpoint speed From version 15.00.00
0 ≡ The starting value at quick stop is the actual speed if
it derives more than 5 rpm from the setpoint. This serves
to prevent a jump to a strongly differing setpoint.
1 ≡ The starting value for quick stop is the setpoint
speed .
Bit 4 Use position encoder From version 15.00.00
1 ≡ In case of quick stop with position control, the
position encoder is used instead of the speed encoder.
The basic conditions are shown in the flow diagram
for
the quick stop function.
Bit 5 Standstill depending on the actual
speed
Bit 6 Reserved
Bit 7 Reserved
Bit 8 Reserved
Bit 9 Reserved
Bit 10 Reserved
Bit 11 Reserved
Bit 12 Reserved
