Lenze 8400 - Page 1026

15 Parameter reference
15.2 Parameter list
1026
Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00952
C00953
C00959
C00960
Parameter | Name:
C00952 | L_Interpolator_1: Limit value - error cycles
Data type: UNSIGNED_16
Index: 23623
d
= 5C47
h
From version 04.00.00
The L_Interpolator_1
FB: Limit value for missing data telegrams
Setting range (min. value | unit | max. value) Lenze setting
0 65535 5
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00953 | L_Interpolator_1: Speed-up
Data type: UNSIGNED_8
Index: 23622
d
= 5C46
h
From version 04.00.00
FB L_Interpolator_1
: Limitation of the number of correction increments per cycle (speed-up)
Setting range (min. value | unit | max. value) Lenze setting
0 100 0
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00959 | L_Curve: Current output value
Data type: INTEGER_16
Index: 23616
d
= 5C40
h
From version 11.00.00
FB L_Curve_1
: Display of the current output value nOut_a
Display range (min. value | unit | max. value)
-199.99 % 199.99
Subcodes Info
C00959/1 L_Curve_1
: Current output value
C00959/2 L_Curve_2
: Current output value
C00959/3 L_Curve_3: Current output value
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
Parameter | Name:
C00960 | L_Curve_1: Selected curve type
Data type: UNSIGNED_8
Index: 23615
d
= 5C3F
h
From version 04.00.00
FB L_Curve_1
: Selected curve type
Selection list
0Out = 0
1Out = In
2Out = f(In)
3Out = f(table)
Subcodes Lenze setting Info
C00960/1 1: Out = In L_Curve_1
: Function
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
