Lenze 8400 - Page 1027

Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23 1027
15 Parameter reference
15.2 Parameter list
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00961
C00963
C00964
Parameter | Name:
C00961 | L_Curve_1: Input limitation
Data type: INTEGER_16
Index: 23614
d
= 5C3E
h
From version 04.00.00
FB L_Curve_1
: Upper and lower limit for input value
Setting range (min. value | unit | max. value)
-199.99 % 199.99
Subcodes Lenze setting Info
C00961/1 199.99 % L_Curve_1
: Max. input
C00961/2 -199.99 % L_Curve_1
: Min. input
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
Parameter | Name:
C00963 | L_Curve_1: Table X-values
Data type: INTEGER_16
Index: 23612
d
= 5C3C
h
From version 04.00.00
FB L_Curve_1
: X-values for characteristic function
Setting range (min. value | unit | max. value)
-32767 32767
Subcodes Lenze setting Info
C00963/1 0 X values 1 ... 32 for characteristic function
C00963/...
C00963/32
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00964 | L_Curve_1: Table Y-values
Data type: INTEGER_16
Index: 23611
d
= 5C3B
h
From version 04.00.00
FB L_Curve_1
: Y-value for characteristic function
Setting range (min. value | unit | max. value)
-32767 32767
Subcodes Lenze setting Info
C00964/1 0 Y values 1 ... 32 for characteristic function
C00964/...
C00964/32
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
