Lenze 8400 - Page 1028

15 Parameter reference
15.2 Parameter list
1028
Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00965
C00966
C00967
Parameter | Name:
C00965 | Max. motor speed
Data type: UNSIGNED_16
Index: 23610
d
= 5C3A
h
From version 10.00.00
When the drive reaches the motor speed set here:
• The "Fault" error response takes place, i.e. the motor is shut down immediately.
• The error message "oS2: Max. motor speed reached
" is entered into the logbook.
Setting range (min. value | unit | max. value) Lenze setting
50 rpm 65000 60000 rpm
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00966 | VFC: Time const. slip comp.
Data type: UNSIGNED_16
Index: 23609
d
= 5C39
h
Filter time constant of the slip compensation for V/f characteristic control (VFCplus)
• The time constant of slip compensation serves to specify the dynamics of slip compensation for V/f characteristic
control without feedback.
• The lower the selected time constant, the higher the dynamic performance of the slip compensation.
Setting range (min. value | unit | max. value) Lenze setting
1 ms 6000 power-related (see table
)
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00967 | VFC: Frequency interpol. point n
Data type: INTEGER_16
Index: 23608
d
= 5C38
h
From version 04.00.00
Selection of the interpolation points (frequency values) for the V/f characteristic control (VFCplus
) with user-
definable V/f characteristic (C00006
= "10")
Setting range (min. value | unit | max. value)
-2600.0 Hz 2600.0
Subcodes Lenze setting Info
C00967/1 -50.0 Hz VFC: Frequency interpol. point 1
C00967/2 -40.0 Hz VFC
: Frequency interpol. point 2
C00967/3 -30.0 Hz VFC
: Frequency interpol. point 3
C00967/4 -20.0 Hz VFC: Frequency interpol. point 4
C00967/5 -10.0 Hz VFC
: Frequency interpol. point 5
C00967/6 0.0 Hz VFC
: Frequency interpol. point 6
C00967/7 10.0 Hz VFC
: Frequency interpol. point 7
C00967/8 20.0 Hz VFC
: Frequency interpol. point 8
C00967/9 30.0 Hz VFC
: Frequency interpol. point 9
C00967/10 40.0 Hz VFC
: Frequency interpol. point 10
C00967/11 50.0 Hz VFC
: Frequency interpol. point 11
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 10
