Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23 1029
15 Parameter reference
15.2 Parameter list
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00968
C00969
C00970
Parameter | Name:
C00968 | VFC: Voltage interpol. point n
Data type: UNSIGNED_16
Index: 23607
d
= 5C37
h
From version 04.00.00
Selection of the interpolation points (voltage values) for the V/f characteristic control (VFCplus
) with user-definable
V/f characteristic (C00006
="10")
Setting range (min. value | unit | max. value)
0.00 V 600.00
Subcodes Lenze setting Info
C00968/1 400.00 V VFC
: Voltage interpol. point 1
C00968/2 320.00 V VFC
: Voltage interpol. point 2
C00968/3 240.00 V VFC
: Voltage interpol. point 3
C00968/4 160.00 V VFC
: Voltage interpol. point 4
C00968/5 80.00 V VFC
: Voltage interpol. point 5
C00968/6 0.00 V VFC
: Voltage interpol. point 6
C00968/7 80.00 V VFC
: Voltage interpol. point 7
C00968/8 160.00 V VFC
: Voltage interpol. point 8
C00968/9 240.00 V VFC
: Voltage interpol. point 9
C00968/10 320.00 V VFC
: Voltage interpol. point 10
C00968/11 400.00 V VFC
: Voltage interpol. point 11
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
Parameter | Name:
C00969 | Motorparameter
Data type: UNSIGNED_8
Index: 23606
d
= 5C36
h
From version 12.00.00
Display range (min. value | unit | max. value)
1 255
Subcodes Info
C00969/1 Motor - number of pole pairs
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00970 | Rated device voltage
Data type: UNSIGNED_16
Index: 23605
d
= 5C35
h
Display range (min. value | unit | max. value)
0 V 1000
Subcodes Info
C00970/1 Rated device voltage
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
