C00007
8 VFCplus: V/f quadr This control type is used for speed control of an
asynchronous motor via a square-law V/f characteristic.
• For setting the V/f characteristic, only the rated
frequency (C00089
) and the rated voltage (C00090) of
the motor have to be entered.
V/f characteristic control
9 VFCplus: V/f quadr + encoder This control type is used for speed control of an
asynchronous motor via a square-law V/f characteristic.
• The control type requires a speed feedback via an
encoder mounted to the motor!
• For setting the V/f characteristic, only the rated
frequency (C00089
) and the rated voltage (C00090) of
the motor have to be entered.
V/f control
10 VFCplus: V/f definable From version 04.00.00
This type of control is used for the speed control of an
asynchronous motor via a user-definable characteristic
with several interpolation points.
• For setting the V/f characteristic, only the rated
frequency (C00089
) and the rated voltage (C00090) of
the motor have to be entered.
V/f characteristic control
11 VFCplusEco: V/f energy-saving From version 10.00.00
This control type is used for energy-saving speed control
of an asynchronous motor via a linear V/f characteristic.
• For setting the V/f characteristic, only the rated
frequency (C00089
) and the rated voltage (C00090) of
the motor have to be entered.
• Predestinated application areas of this control type
are materials handling technology and pump and fan
systems.
V/f characteristic control, energy-saving
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00006 | Motor control
Data type: UNSIGNED_8
Index: 24569
d
= 5FF9
h
Parameter | Name:
C00007 | Control mode
Data type: UNSIGNED_16
Index: 24568
d
= 5FF8
h
With this parameter the control mode for the technology application selected under C00005 is defined, i.e. how the
inputs and outputs of the technology application are connected to the I/Os of the inverter.
• How the inputs and outputs are connected in the individual control modes is described in the corresponding
technology application:
• "Actuating drive speed" TA
• TA "actuating drive speed (AC Drive Profile)"
• TA "Table positioning"
• "Switch-off positioning" TA
Selection list (Lenze setting printed in bold) Info
0 Wiring has changed This is displayed when the FB interconnection has been
changed in the I/O level via the FB Editor.
10 Terminals 0 The technology application is controlled via the digital
and analog input terminals of the inverter.
• A short overview of the preconfigured terminal
assignment is included in the description of the
respective technology application in the "Terminal
assignment of the control modes".
12 Terminals 2
14 Terminals 11
16 Terminal 16
